Roland Sound Canvas SC-8850 User Manual

220
Appendices
Parameter Setting Value Value (Hex.) MSB/LSB (H)
41 : EH → Chorus 02 06
+ EH Sens 0–64–127 00–7F 03
EH Mix 0–127 00–7F 04
Cho Dly 0–14ms–100ms *1 08
Cho Rate 0.05–0.45–10.0 *6 09
Cho Depth 0–101–127 00–7F 0A
# Cho Bal D> 0E–D=E–D 0<E 00–7F 0C
Low Gain -12–0–+12 34–4C 13
Hi Gain -12–0–+12 34–4C 14
Level 0–80–127 00–7F 16
42 : EH → Flanger 02 07
+ EH Sens 0–64–127 00–7F 03
EH Mix 0–127 00–7F 04
FL Dly 0–1.6ms–100ms *1 08
FL Rate 0.05–0.60–10.0 *6 09
FL Depth 0–24–127 00–7F 0A
FL Fb -98%–+80%–+98% 0F–71 0B
# FL Bal D> 0E–D>74E–D 0<E 00–7F 0C
Low Gain -12–0–+12 34–4C 13
Hi Gain -12–0–+12 34–4C 14
Level 0–96–127 00–7F 16
43 : EH → Delay 02 08
+ EH Sens 0–64–127 00–7F 03
EH Mix 0–127 00–7F 04
Dly Time 0–250ms–500ms *4 08
Dly Fb -98%–+32%–+98% 0F–71 09
Dly HF 315–8k/Bypass *8 0A
# Dly Bal D> 0E–D>74E–D 0<E 00–7F 0C
Low Gain -12–0–+12 34–4C 13
Hi Gain -12–0–+12 34–4C 14
Level 0–88–127 00–7F 16
44 : Cho → Delay 02 09
Cho Dly 0–1.0ms–100ms *1 03
Cho Rate 0.05–0.50–10.0 *6 04
Cho Depth 0–120–127 00–7F 05
+ Cho Bal D> 0E–D=E–D 0<E 00–7F 07
Dly Time 0–250ms–500ms *4 08
Dly Fb -98%–+32%–+98% 0F–71 09
Dly HF 315–8k/Bypass *8 0A
# Dly Bal D> 0E–D>74E–D 0<E 00–7F 0C
Low Gain -12–0–+12 34–4C 13
Hi Gain -12–0–+12 34–4C 14
Level 0–127 00–7F 16
45 : FL → Delay 02 0A
FL Dly 0–1.6ms–100ms *1 03
FL Rate 0.05–0.60–10.0 *6 04
FL Depth 0–24–127 00–7F 05
+ FL Fb -98%–+80%–+98% 0F–71 06
FL Bal D> 0E–D=E–D 0<E 00–7F 07
Dly Time 0–250ms–500ms *4 08
Dly Fb -98%–+32%–+98% 0F–71 09
Dly HF 315–8k/Bypass *8 0A
# Dly Bal D> 0E–D>74E–D 0<E 00–7F 0C
Low Gain -12–0–+12 34–4C 13
Hi Gain -12–0–+12 34–4C 14
Level 0–127 00–7F 16
Parameter Setting Value Value (Hex.) MSB/LSB (H)
46 : Cho→ Flanger 02 0B
Cho Dly 0–1.0ms–100ms *1 03
Cho Rate 0.05–0.45–10.0 *6 04
Cho Depth 0–120–127 00–7F 05
+ Cho Bal D> 0E–D=E–D 0<E 00–7F 07
FL Dly 0–1.6ms–100ms *1 08
FL Rate 0.05–0.60–10.0 *6 09
FL Depth 0–24–127 00–7F 0A
FL Fb -98%–+80%–+98% 0F–71 0B
# FL Bal D> 0E–D=E–D 0<E 00–7F 0C
Low Gain -12–0–+12 34–4C 13
Hi Gain -12–0–+12 34–4C 14
Level 0–112–127 00–7F 16
❍ Effects that connect three or more types of
effect in series (series 3/4/5)
47 : Rotary Multi 03 00
+ OD Drive 0–13–127 00–7F 03
OD Sw Off/On 00/01 04
EQ L Gain -12–0–+12 34–4C 05
EQ M Fq 200–1.6k–6.3k *10 06
EQ M Q 0.5/1.0/2.0/4.0/9.0 00/01/02/03/04 07
EQ M Gain -12–0–+12 34–4C 08
EQ H Gain -12–0–+12 34–4C 09
RT L Slow 0.05–0.35–10.0 *6 0A
RT L Fast 0.05–6.40–10.0 *6 0B
RT Lo Accl 0–3–15 *14 0C
RT Lo Lev 0–127 00–7F 0D
RT H Slow 0.05–0.90–10.0 *6 0E
RT H Fast 0.05–7.50–10.0 *6 0F
RT Hi Accl 0–11–15 *14 10
RT Hi Lev 0–64–127 00–7F 11
RT Sept 0–96–127 00–7F 12
# RT Speed Slow/Fast 00/7F 13
Level 0–96–127 00–7F 16
48 : GTR Multi 1 04 00
Cmp Atck 0–100–127 00–7F 03
Cmp Sus 0–80–127 00–7F 04
Cmp Level 0–100–127 00–7F 05
Cmp Sw Off/On 00/01 06
OD Sel Odrv/Dist 00/01 07
+ OD Drive 0–80–127 00–7F 08
OD Amp Small/BltIn/2-Stk/3-Stk 00/01/02/03 09
OD Amp Sw Off/On 00/01 0A
OD L Gain -12–+5–+12 34–4C 0B
OD H Gain -12–+10–+12 34–4C 0C
OD Sw Off/On 00/01 0D
CF Sel Chorus/Flangr 00/01 0E
CF Rate 0.05–0.45–6.40 *7 0F
CF Depth 0–30–127 00–7F 10
CF Fb -98%–+76%–+98% 0F–71 11
CF Mix 0–40–127 00–7F 12
Dly Time 0–300ms–635ms *5 13
Dly Fb 0–34–127 00–7F 14
# Dly Mix 0–15–127 00–7F 15
Level 0–110–127 00–7F 16
