221
Appendices
Parameter Setting Value Value (Hex.) MSB/LSB (H)
49 : GTR Multi 2 04 01
Cmp Atck 0–70–127 00–7F 03
Cmp Sus 0–127 00–7F 04
Cmp Level 0–90–127 00–7F 05
Cmp Sw Off/On 00/01 06
OD Sel Odrv/Dist 00/01 07
+ OD Drive 0–80–127 00–7F 08
OD Amp Small/BltIn/2-Stk/3-Stk 00/01/02/03 09
OD Amp Sw Off/On 00/01 0A
OD Sw Off/On 00/01 0B
EQ L Gain -12–+12 34–4C 0C
EQ M Fq 200–1k–6.3k *10 0D
EQ M Q 0.5/1.0/2.0/4.0/9.0 00/01/02/03/04 0E
EQ M Gain -12–+5–+12 34–4C 0F
EQ H Gain -12–-10–+12 34–4C 10
CF Sel Chorus/Flangr 00/01 11
CF Rate 0.05–0.45–6.40 *7 12
CF Depth 0–96–127 00–7F 13
CF Fb -98%–+76%–+98% 0F–71 14
# CF Mix 0–127 00–7F 15
Level 0–80–127 00–7F 16
50 : GTR Multi 3 04 02
Wah Fil LPF/BPF 00/01 03
+ Wah Man 0–60–127 00–7F 04
Wah Peak 0–10–127 00–7F 05
Wah Sw Off/On 00/01 06
OD Sel Odrv/Dist 00/01 07
# OD Drive 0–80–127 00–7F 08
OD Amp Small/BltIn/2-Stk/3-Stk 00/01/02/03 09
OD Amp Sw Off/On 00/01 0A
OD L Gain -12–0–+12 34–4C 0B
OD H Gain -12–0–+12 34–4C 0C
OD Sw Off/On 00/01 0D
CF Sel Chorus/Flangr 00/01 0E
CF Rate 0.05–0.45–6.40 *7 0F
CF Depth 0–127 00–7F 10
CF Fb -98%–+50%–+98% 0F–71 11
CF Mix 0–50–127 00–7F 12
Dly Time 0–160ms–635ms *5 13
Dly Fb 0–64–127 00–7F 14
Dly Mix 0–30–127 00–7F 15
Level 0–88–127 00–7F 16
51 : Clean Gt Multi 1 04 03
Cmp Atck 0–50–127 00–7F 03
Cmp Sus 0–127 00–7F 04
Cmp Level 0–75–127 00–7F 05
Cmp Sw Off/On 00/01 06
EQ L Gain -12–+12 34–4C 07
EQ M Fq 200–6.3k *10 08
EQ M Q 0.5/1.0/2.0/4.0/9.0 00/01/02/03/04 09
EQ M Gain -12–+5–+12 34–4C 0A
EQ H Gain -12–+12 34–4C 0B
CF Sel Chorus/Flangr 00/01 0C
CF Rate 0.05–0.45–6.40 *7 0D
CF Depth 0–40–127 00–7F 0E
CF Fb -98%–+30%–+98% 0F–71 0F
+ CF Mix 0–100–127 00–7F 10
Dly Time 0–120ms–635ms *5 11
Dly Fb 0–40–127 00–7F 12
Dly HF 315–8k/Bypass *8 13
# Dly Mix 0–30–127 00–7F 14
Level 0–95–127 00–7F 16
Parameter Setting Value Value (Hex.) MSB/LSB (H)
52 : Clean Gt Multi2 04 04
AW Filter LPF/BPF 00/01 03
+ AW Man 0–55–127 00–7F 04
AW Peak 0–40–127 00–7F 05
AW Rate 0.05–1.50–6.40 *7 06
AW Depth 0–80–127 00–7F 07
AW Sw Off/On 00/01 08
EQ L Gain -12–+12 34–4C 09
EQ M Fq 200–1.6k–6.3k *10 0A
EQ M Q 0.5/1.0/2.0/4.0/9.0 00/01/02/03/04 0B
EQ M Gain -12–0–+12 34–4C 0C
EQ H Gain -12–0–+12 34–4C 0D
CF Sel Chorus/Flangr 00/01 0E
CF Rate 0.05–0.45–6.40 *7 0F
CF Depth 0–20–127 00–7F 10
CF Fb -98%–+76%–+98% 0F–71 11
CF Mix 0–100–127 00–7F 12
Dly Time 0–30ms–635ms *5 13
Dly Fb 0–15–127 00–7F 14
# Dly Mix 0–80–127 00–7F 15
Level 0–76–127 00–7F 16
53 : Bass Multi 04 05
Cmp Atck 0–72–127 00–7F 03
Cmp Sus 0–100–127 00–7F 04
Cmp Level 0–75–127 00–7F 05
Cmp Sw Off/On 00/01 06
OD Sel Odrv/Dist 00/01 07
+ OD Drive 0–48–127 00–7F 08
OD Amp Small/BltIn/2-Stk 00/01/02 09
OD Amp Sw Off/On 00/01 0A
OD Sw Off/On 00/01 0B
EQ L Gain -12–+2–+12 34–4C 0C
EQ M Fq 200–1.6k–6.3k *10 0D
EQ M Q 0.5/1.0/2.0/4.0/9.0 00/01/02/03/04 0E
EQ M Gain -12–+4–+12 34–4C 0F
EQ H Gain -12–0 –+12 34–4C 10
CF Sel Chorus/Flangr 00/01 11
CF Rate 0.05–0.30–6.40 *7 12
CF Depth 0–20–127 00–7F 13
CF Fb -98%–+76%–+98% 0F–71 14
# CF Mix 0–64–127 00–7F 15
Level 0–76–127 00–7F 16
54 : Rhodes Multi 04 06
EH Sens 0–64–127 00–7F 03
EH Mix 0–64–127 00–7F 04
PH Man 100–620–8k *12 05
PH Rate 0.05–0.85–6.40 *7 06
PH Depth 0–32–127 00–7F 07
PH Reso 0–16–127 00–7F 08
PH Mix 0–64–127 00–7F 09
CF Sel Chorus/Flangr 00/01 0A
CF LPF 250–6.3k/Bypass *11 0B
CF Dly 0–1.0ms–100ms *1 0C
CF Rate 0.05–0.45–6.40 *7 0D
CF Depth 0–64–127 00–7F 0E
CF Fb -98%–+80%–+98% 0F–71 0F
CF Mix 0–127 00–7F 10
TP Sel Trem/Pan 00/01 11
TP Mod WV Tri/Sqr/Sin/Saw1/Saw2 00/01/02/03/04 12
+ TP Mod RT 0.05–3.05–6.40 *7 13
# TP Mod Dep 0–64–127 00–7F 14
TP Sw Off/On 00/01 15
Level 0–127 00–7F 16
