Appendices
Parameter Setting Value Value (Hex.) MSB/LSB (H)
55 : Keyboard Multi 05 00
+ RM Mod Freq 0–50–127 00–7F 03
# RM Bal D> 0E–D>30E–D 0<E 00–7F 04
EQ L Gain -12–+3–+12 34–4C 05
EQ M Fq 200–6.3k *10 06
EQ M Q 0.5/1.0/2.0/4.0/9.0 00/01/02/03/04 07
EQ M Gain -12–+5–+12 34–4C 08
EQ H Gain -12–-3–+12 34–4C 09
PS Coarse -24–+7–+12 28–4C 0A
PS Fine -100–0–+100 0E–72 0B
PS Mode 1–500–04 0C
PS Bal D> 0E–D>60E–D 0<E 00–7F 0D
PH Man 100–620–8k *12 0E
PH Rate 0.05–0.45–6.40 *7 0F
PH Depth 0–90–127 00–7F 10
PH Reso 0–80–127 00–7F 11
PH Mix 0–75–127 00–7F 12
Dly Time 0–100ms–635ms *5 13
Dly Fb 0–64–127 00–7F 14
Dly Mix 0–40–127 00–7F 15
Level 0–96–127 00–7F 16
❍ Effects that connect two types of effect in
parallel (parallel 2)
56 : Cho / Delay 11 00
Cho Dly 0–1.0ms–100ms *1 03
Cho Rate 0.05–0.45–10.0 *6 04
Cho Depth 0–120–127 00–7F 05
+ Cho Bal D> 0E–D=E–D 0<E 00–7F 07
Cho Pan L63–0–R63 00–7F 12
Cho Level 0–127 00–7F 13
Dly Time 0–250ms–500ms *4 08
Dly Fb -98%–+32%–+98% 0F–71 09
Dly HF 315–8k/Bypass *8 0A
# Dly Bal D> 0E–D>61E–D 0<E 00–7F 0C
Dly Pan L63–0–R63 00–7F 14
Dly Level 0–127 00–7F 15
Level 0–96–127 00–7F 16
57 : FL / Delay 11 01
FL Dly 0–1.6ms–100ms *1 03
FL Rate 0.05–0.60–10.0 *6 04
FL Depth 0–24–127 00–7F 05
FL Fb -98%–+80%–+98% 0F–71 06
+ FL Bal D> 0E–D=E–D 0<E 00–7F 07
FL Pan L63–0–R63 00–7F 12
FL Level 0–127 00–7F 13
Dly Time 0–250ms–500ms *4 08
Dly Fb -98%–+32%–+98% 0F–71 09
Dly HF 315–8k/Bypass *8 0A
# Dly Bal D> 0E–D>74E–D 0<E 00–7F 0C
Dly Pan L63–0–R63 00–7F 14
Dly Level 0–127 00–7F 15
Level 0–96–127 00–7F 16
58 : Cho / Flanger 11 02
Cho Dly 0–1.6ms–100ms *1 03
Cho Rate 0.05–0.45–10.0 *6 04
Cho Depth 0–120–127 00–7F 05
+ Cho Bal D> 0E–D=E–D 0<E 00–7F 07
Cho Pan L63–0–R63 00–7F 12
Cho Level 0–127 00–7F 13
FL Dly 0–1.6ms–100ms *1 08
FL Rate 0.05–0.60–10.0 *6 09
FL Depth 0–24–127 00–7F 0A
FL Fb -98%–+80%–+98% 0F–71 0B
# FL Bal D> 0E–D=E–D 0<E 00–7F 0C
FL Pan L63–0–R63 00–7F 14
FL Level 0–127 00–7F 15
Level 0–88 -127 00–7F 16
Parameter Setting Value Value (Hex.) MSB/LSB (H)
59 : OD1 / OD2 11 03
OD1 Sel Odrv/Dist 00/01 03
+ OD1 Drive 0–48–127 00–7F 04
OD1 Amp Small/BltIn/2-Stk/3-Stk 00/01/02/03 05
OD1 Amp Sw Off/On 00/01 06
OD1 Pan L63–0–R63 00–7F 12
OD1 Level 0–96–127 00–7F 13
OD2 Sel Odrv/Dist 00/01 08
# OD2 Drive 0–76–127 00–7F 09
OD2 Amp Small/BltIn/2-Stk/3-Stk 00/01/02/03 0A
OD2 Amp Sw Off/On 00/01 0B
OD2 Pan L63–0–R63 00–7F 14
OD2 Level 0–84–127 00–7F 15
Level 0–127 00–7F 16
60 : OD / Rotary 11 04
OD Sel Odrv/Dist 00/01 03
+ OD Drive 0–48–127 00–7F 04
OD Amp Small/BltIn/2-Stk/3-Stk 00/01/02/03 05
OD Amp Sw Off/On 00/01 06
OD Pan L63–0–R63 00–7F 12
OD Level 0–96–127 00–7F 13
RT L Slow 0.05–0.35–10.0 *6 08
RT L Fast 0.05–6.40 -10.0 *6 09
RT Lo Accl 0–3–15 *14 0A
RT Lo Lev 0–127 00–7F 0B
RT H Slow 0.05–0.90–10.0 *6 0C
RT H Fast 0.05–7.50–10.0 *6 0D
RT Hi Accl 0–11–15 *14 0E
RT Hi Lev 0–64–127 00–7F 0F
RT Sept 0–96–127 00–7F 10
# RT Speed Slow/Fast 00/7F 11
RT Pan L63–0–R63 00–7F 14
RT Level 0–127 00–7F 15
Level 0–127 00–7F 16
61 : OD / Phaser 11 05
OD Sel Odrv/Dist 00/01 03
+ OD Drive 0–48–127 00–7F 04
OD Amp Smal/BltIn/ 2-Stk/3-Stk 00/01/02/03 05
OD Amp Sw Off/On 00/01 06
OD Pan L63–0–R63 00–7F 12
OD Level 0–96–127 00–7F 13
PH Man 100–620 –8k *12 08
# PH Rate 0.05–0.85–10.0 *6 09
PH Depth 0–64–127 00–7F 0A
PH Reso 0–16–127 00–7F 0B
PH Mix 0–127 00–7F 0C
PH Pan L63–0–R63 00–7F 14
PH Level 0–127 00–7F 15
Level 0–127 00–7F 16
62 : OD / AutoWah 11 06
OD Sel Odrv/Dist 00/01 03
+ OD Drive 0–48–127 00–7F 04
OD Amp Small/BltIn/2-Stk/3-Stk 00/01/02/03 05
OD Amp Sw Off/On 00/01 06
OD Pan L63–0–R63 00–7F 12
OD Level 0–96–127 00–7F 13
AW Filter LPF/BPF 00/01 08
AW Sens 0–127 00–7F 09
# AW Man 0–68–127 00–7F 0A
AW Peak 0–62–127 00–7F 0B
AW Rate 0.05–2.05–10.0 *6 0C
AW Depth 0–72–127 00–7F 0D
AW Pol Down/Up 00/01 0E
AW Pan L63–0–R63 00–7F 14
AW Level 0–127 00–7F 15
Level 0–127 00–7F 16
