231
Appendices
❍Master Coarse Tuning [8850]
Status Data byte Status
F0H 7FH,7FH,04H,04H,llH,mmH F7
Byte Explanation
F0H Exclusive status
7FH ID number (universal realtime message)
7FH Device ID (Broadcast)
04H Sub ID#1 (Device Control)
04H Sub ID#2 (Master Coarse Tuning)
llH Master Coarse Tuning LSB
mmH Master Coarse Tuning MSB
F7H EOX (End Of Exclusive)
llH : ignored (processed as 00H)
mmH : 28H – 40H – 58H (-24 – 0 – +24 [semitones])
●Global Parameter Control
Parameters of the Global Parameter Control are newly provided for the General MIDI 2.
❍Reverb Parameters [8850]
Status Data byte Status
F0H 7FH,7FH,04H,05H,01H,01H,01H,01H,01H,ppH,vvH F7H
Byte Explanation
F0H Exclusive status
7FH ID number (universal realtime message)
7FH Device ID (Broadcast)
04H Sub ID#1 (Device Control)
05H Sub ID#2 (Global Parameter Control)
01H Slot path length
01H Parameter ID width
01H Value width
01H Slot path MSB
01H Slot path LSB (Effect 0101: Reverb)
ppH Parameter to be controlled.
vvH Value for the parameter.
F7H EOX (End Of Exclusive)
pp=0 Reverb Type
vv = 00H Small Room (Room1)
vv = 01H Medium Room (Room2)
vv = 02H Large Room (Room3)
vv = 03H Medium Hall (Hall1)
vv = 04H Large Hall (Hall2)
vv = 08H Plate (Plate)
* The SC-8850 displays Reverb Type as described in the parenthesis.
pp=1 Reverb Time
vv = 00H – 7FH 0 – 127
❍Chorus Parameters [8850]
Status Data byte Status
F0H 7FH,7FH,04H,05H,01H,01H,01H,01H,02H,ppH,vvH F7H
Byte Explanation
F0H Exclusive status
7FH ID number (universal realtime message)
7FH Device ID (Broadcast)
04H Sub ID#1 (Device Control)
05H Sub ID#2 (Global Parameter Control)
01H Slot path length
01H Parameter width
01H Value width
01H Slot path MSB
02H Slot path LSB (Effect 0102: Chorus)
ppH Parameter to be controlled.
vvH Value for the parameter.
F7H EOX (End Of Exclusive)
pp=0 Chorus Type
vv=0 Chorus1
vv=1 Chorus2
vv=2 Chorus3
vv=3 Chorus4
vv=4 FB Chorus
vv=5 Flanger
pp=1 Mod Rate
vv= 00H – 7FH 0 – 127
pp=2 Mod Depth
vv = 00H – 7FH 0 – 127
pp=3 Feedback
vv = 00H – 7FH 0 – 127
pp=4 Send To Reverb
vv = 00H – 7FH 0 – 127
❍Channel Pressure [8850]
Status Data byte Status
F0H 7FH,7FH,09H,01H,0nH,ppH,rrH F7H
Byte Explanation
F0H Exclusive status
7FH ID number (universal realtime message)
7FH Device ID (Broadcast)
09H Sub ID#1 (Controller Destination Setting)
01H Sub ID#2 (Channel Pressure)
0nH MIDI Channel (00 – 0F)
ppH Controlled parameter
rrH Controlled range
F7H EOX (End Of Exclusive)
pp=0 Pitch Control
rr = 28H – 58H -24 – +24 [semitones]
pp=1 Filter Cutoff Control
rr = 00H – 7FH -9600 – +9450 [cents]
pp=2 Amplitude Control
rr = 00H – 7FH 0 – 200%
pp=3 LFO Pitch Depth
rr = 00H – 7FH 0 – 600 [cents]
pp=4 LFO Filter Depth
rr = 00H – 7FH 0 – 2400 [cents]
pp=5 LFO Amplitude Depth
rr = 00H – 7FH 0 – 100%
❍Controller [8850]
Status Data byte Status
F0H 7FH,7FH,09H,03H,0nH,ccH,ppH,rrH F7H
Byte Explanation
F0H Exclusive status
7FH ID number (universal realtime message)
7FH Device ID (Broadcast)
09H Sub ID#1 (Controller Destination Setting)
03H Sub ID#2 (Control Change)
0nH MIDI Channel (00 – 0F)
ccH Controller number (01 – 1F, 40 – 5F)
ppH Controlled parameter
rrH Controlled range
F7H EOX (End Of Exclusive)
pp=0 Pitch Control
rr = 28H – 58H -24 – +24 [semitones]
pp=1 Filter Cutoff Control
rr = 00H – 7FH -9600 – +9450 [cents]
pp=2 Amplitude Control
rr = 00H – 7FH 0 – 200%
pp=3 LFO Pitch Depth
rr = 00H – 7FH 0 – 600 [cents]
pp=4 LFO Filter Depth
rr = 00H – 7FH 0 – 2400 [cents]
pp=5 LFO Amplitude Depth
rr = 00H – 7FH 0 – 100%
