236
Appendices
Address(H) Size(H) Data(H) Parameter Description Default Value (H) Description
40 01 38 00 00 01 00 – 07 CHORUS MACRO 00: Chorus 1 02 Chorus 3
01: Chorus 2
02: Chorus 3
03: Chorus 4
04: Feedback Chorus
05: Flanger
06: Short Delay
07: Short Delay(FB)
40 01 39 00 00 01 00 – 07 CHORUS PRE-LPF 0-7 00 0
40 01 3A 00 00 01 00 – 7F CHORUS LEVEL 0-127 40 64
40 01 3B 00 00 01 00 – 7F CHORUS FEEDBACK 0-127 08 8
40 01 3C 00 00 01 00 – 7F CHORUS DELAY 0-127 50 80
40 01 3D 00 00 01 00 – 7F CHORUS RATE 0-127 03 3
40 01 3E 00 00 01 00 – 7F CHORUS DEPTH 0-127 13 19
40 01 3F 00 00 01 00 – 7F CHORUS SEND LEVEL TO REVERB 0-127 00 0
40 01 40 00 00 01 00 – 7F CHORUS SEND LEVEL TO DELAY 0-127 00 0
* CHORUS MACRO is a macro parameter that allows global setting of chorus parameters. When you select the chorus type with CHORUS MACRO, each chorus parameter will be set to their
most suitable value.
40 01 50 00 00 01 00 – 09 DELAY MACRO 00: Delay 1 00 Delay1
01: Delay 2
02: Delay 3
03: Delay 4
04: Pan Delay 1
05: Pan Delay 2
06: Pan Delay 3
07: Pan Delay 4
08: Delay to Reverb
09: Pan Repeat
40 01 51 00 00 01 00 – 07 DELAY PRE-LPF 0 – 700 0
40 01 52 00 00 01 01 – 73 DELAY TIME CENTER 0.1 ms – 1 sec 61 340
40 01 53 00 00 01 01 – 78 DELAY TIME RATIO LEFT 4 – 500% 01 4
40 01 54 00 00 01 01 – 78 DELAY TIME RATIO RIGHT 4 – 500% 01 4
40 01 55 00 00 01 00 – 7F DELAY LEVEL CENTER 0 – 127 7F 127
40 01 56 00 00 01 00 – 7F DELAY LEVEL LEFT 0 – 127 00 0
40 01 57 00 00 01 00 – 7F DELAY LEVEL RIGHT 0 – 127 00 0
40 01 58 00 00 01 00 – 7F DELAY LEVEL 0 – 127 40 64
40 01 59 00 00 01 00 – 7F DELAY FEEDBACK -64 – +63 50 +16
40 01 5A 00 00 01 00 – 7F DELAY SENDLEVEL TO REVERB 0 – 127 00 0
* DELAY MACRO is a macro parameter that allows global setting of delay parameters. When you select the delay type with DELAY MACRO, each delay parameter will be set to their most
suitable value.
* The relation between the DELAY TIME CENTER value and the actual delay time is as follows.
DELAY TIME Time Range [ms] Resolution [ms]
01 – 14 0.1 – 2.0 0.1
14 – 23 2.0 – 5.0 0.2
23 – 2D 5.0 – 10.0 0.5
2D – 37 10.0 – 20.0 1.0
37 – 46 20.0 – 50.0 2.0
46 – 50 50.0 – 100.0 5.0
50 – 5A 100.0 – 200.0 10.0
5A – 69 200.0 – 500.0 20.0
69 – 73 500.0 – 1000.0 50.0
* DELAY TIME RATIO LEFT and DELAY TIME RATIO RIGHT specify the ratio in relation to DELAY TIME CENTER. The resolution is 100/24(%).
40 02 00 00 00 01 00 – 01 EQ LOW FREQ 200Hz, 400Hz 00 200Hz
40 02 01 00 00 01 34 – 4C EQ LOW GAIN -12 – +12dB 40 0
40 02 02 00 00 01 00 – 01 EQ HIGH FREQ 3kHz, 6kHz 00 3kHz
40 02 03 00 00 01 34 – 4C EQ HIGH GAIN -12 – +12dB 40 0
