Appendices

Address(H) Size(H) Data(H) Parameter Default Value (H) Description

40 03 00 00 00 02 00 – 7F EFX TYPE 00 00 00: Thru

40 03 01#

40 03 03 00 00 01 00 – 7F EFX PARAMETER 1

40 03 04 00 00 01 00 – 7F EFX PARAMETER 2

40 03 05 00 00 01 00 – 7F EFX PARAMETER 3

40 03 06 00 00 01 00 – 7F EFX PARAMETER 4

40 03 07 00 00 01 00 – 7F EFX PARAMETER 5

40 03 08 00 00 01 00 – 7F EFX PARAMETER 6

40 03 09 00 00 01 00 – 7F EFX PARAMETER 7

40 03 0A 00 00 01 00 – 7F EFX PARAMETER 8

40 03 0B 00 00 01 00 – 7F EFX PARAMETER 9

40 03 0C 00 00 01 00 – 7F EFX PARAMETER 10

40 03 0D 00 00 01 00 – 7F EFX PARAMETER 11

40 03 0E 00 00 01 00 – 7F EFX PARAMETER 12

40 03 0F 00 00 01 00 – 7F EFX PARAMETER 13

40 03 10 00 00 01 00 – 7F EFX PARAMETER 14

40 03 11 00 00 01 00 – 7F EFX PARAMETER 15

40 03 12 00 00 01 00 – 7F EFX PARAMETER 16

40 03 13 00 00 01 00 – 7F EFX PARAMETER 17

40 03 14 00 00 01 00 – 7F EFX PARAMETER 18

40 03 15 00 00 01 00 – 7F EFX PARAMETER 19

40 03 16 00 00 01 00 – 7F EFX PARAMETER 20

* Regarding EFX TYPE and EFX PARAMETER, please refer to page 91, 216

Address(H) Size(H) Data(H) Parameter Description Default Value (H) Description

40 03 17 00 00 01 00 – 7F EFX SEND LEVEL TO REVERB 0-127 28 40

40 03 18 00 00 01 00 – 7F EFX SEND LEVEL TO CHORUS 0-127 00 0

40 03 19 00 00 01 00 – 7F EFX SEND LEVEL TO DELAY 0-127 00 0

40 03 1B 00 00 01 00 – 7F EFX CONTROL SOURCE1 Off, CC1-95, CAf, Bend 00 Off

40 03 1C 00 00 01 00 – 7F EFX CONTROL DEPTH1 -100 – 0 – +100 [%] 40 0 (%)

40 03 1D 00 00 01 00 – 7F EFX CONTROL SOURCE2 Off, CC1 – 95, CAf, Bend 00 Off

40 03 1E 00 00 01 00 – 7F EFX CONTROL DEPTH2 -100 – 0 – +100 [%] 40 0 (%)

40 03 1F 00 00 01 00 – 7F EFX SEND EQ SWITCH OFF/ON 01 ON

* EFX TYPE is a macro parameter which sets various Insertion Effect parameters as a group. When you use EFX TYPE to select an Insertion Effect type, each effect parameter will be set to the

most suitable value.

❍Patch Part parameters

The SC-8850 has 16 Parts in Group A, Group B, Group C, and Group D respectively. Parameters that can be set individually for each Part are called Patch Part parameters. If you specify a part in

Group A, specify the address 40 ** ** using the block number to the corresponding part from PORT A (normally MIDI IN 1). If you specify a part in Group B, specify the address 40 ** ** using the

block number to the corresponding part from PORT B (normally MIDI IN 2).

If you use Exclusive messages to set Patch Part parameters, specify the address by Block number rather than Part Number (normally the same number as the MIDI channel). The Block number can

be specified as one of 16 blocks, from 0(H) to F(H).

The relation between Part number and Block number is as follows.

x...BLOCK NUMBER (0 – F), Part 1 (default MIDIch = 1) x=1

Part 2 (default MIDIch = 2) x=2

:::

Part 9 (default MIDIch = 9) x=9

Part10 (default MIDIch =10) x=0

Part11 (default MIDIch =11) x=A

Part12 (default MIDIch =12) x=B

:::

Part16 (default MIDIch =16) x=F

n... MIDI channel number (0 – F) of the BLOCK.
