240
Appendices
Address(H) Size(H) Data(H) Parameter Description Default Value (H) Description
40 2x 42 00 00 01 00 – 7F CC1 AMPLITUDE CONTROL -100.0 – +100.0 [%] 40 0 [%]
40 2x 43 00 00 01 00 – 7F CC1 LFO1 RATE CONTROL -10.0 – +10.0 [Hz] 40 0 [Hz]
40 2x 44 00 00 01 00 – 7F CC1 LFO1 PITCH DEPTH 0 – 600 [cents] 00 0 [cents]
40 2x 45 00 00 01 00 – 7F CC1 LFO1 TVF DEPTH 0 – 2400 [cents] 00 0 [cents]
40 2x 46 00 00 01 00 – 7F CC1 LFO1 TVA DEPTH 0 – 100.0 [%] 00 0 [%]
40 2x 47 00 00 01 00 – 7F CC1 LFO2 RATE CONTROL -10.0 – +10.0 [Hz] 40 0 [Hz]
40 2x 48 00 00 01 00 – 7F CC1 LFO2 PITCH DEPTH 0 – 600 [cents] 00 0 [cents]
40 2x 49 00 00 01 00 – 7F CC1 LFO2 TVF DEPTH 0 – 2400 [cents] 00 0 [cents]
40 2x 4A 00 00 01 00 – 7F CC1 LFO2 TVA DEPTH 0 – 100.0 [%] 00 0 [%]
40 2x 50 00 00 01 28 – 58 CC2 PITCH CONTROL -24 – +24 [semitones] 40 0 [semitones]
40 2x 51 00 00 01 00 – 7F CC2 TVF CUTOFF CONTROL -9600 – +9600 [cents] 40 0 [cents]
40 2x 52 00 00 01 00 – 7F CC2 AMPLITUDE CONTROL -100.0 – +100.0 [%] 40 0 [%]
40 2x 53 00 00 01 00 – 7F CC2 LFO1 RATE CONTROL -10.0 – +10.0 [Hz] 40 0 [Hz]
40 2x 54 00 00 01 00 – 7F CC2 LFO1 PITCH DEPTH 0 – 600 [cents] 00 0 [cents]
40 2x 55 00 00 01 00 – 7F CC2 LFO1 TVF DEPTH 0 – 2400 [cents] 00 0 [cents]
40 2x 56 00 00 01 00 – 7F CC2 LFO1 TVA DEPTH 0 – 100.0 [%] 00 0 [%]
40 2x 57 00 00 01 00 – 7F CC2 LFO2 RATE CONTROL -10.0 – +10.0 [Hz] 40 0 [Hz]
40 2x 58 00 00 01 00 – 7F CC2 LFO2 PITCH DEPTH 0 – 600 [cents] 00 0 [cents]
40 2x 59 00 00 01 00 – 7F CC2 LFO2 TVF DEPTH 0 – 2400 [cents] 00 0 [cents]
40 2x 5A 00 00 01 00 – 7F CC2 LFO2 TVA DEPTH 0 – 100.0 [%] 00 0 [%]
* You may not always be able to obtain the desired effect by modifying the LFO 1 and LFO 2 parameters.
40 4x 00 00 00 01 00 – 04 TONE MAP NUMBER MAP 0 – 400
(= CC#32 : Bank number LSB) 00: SELECTED
01: SC-55 MAP
02: SC-88 MAP
03: SC-88Pro MAP
04: SC-8850 MAP
* When “GS Reset” is received, this will be 00: SELECTED.
40 4x 01 00 00 01 01 – 04 TONE MAP-0 NUMBER 01: SC-55 MAP (04)
02: SC-88 MAP
03: SC-88Pro MAP
04: SC-8850 MAP
* This specifies a MAP when TONE MAP NUMBER is 00.
40 4x 20 00 00 01 00 – 01 EQ ON/OFF OFF/ON 01 ON
* This turns the EQ (equalizer) on/off.
40 4x 21 00 00 01 00 – 03 OUTPUT ASSIGN 00:OUTPUT-1 00 OUTPUT-1
01:OUTPUT-2
02:OUTPUT-2L
03:OUTPUT-2R
40 4x 22 00 00 01 00 – 01 PART EFX ASSIGN 00:BYPASS 00 BYPASS
01:EFX
●Drum setup parameters
m: Map number (0 = MAP1, 1 = MAP2)
rr: drum part note number (00H – 7FH: 0 – 127)
Address(H) Size(H) Data(H) Parameter Description
41 m0 00 00 00 0C 20 – 7F DRUM MAP NAME ASCII Character
| #
41 m0 0B#
41 m1 rr 00 00 01 00 – 7F PLAY NOTE NUMBER Pitch coarse
41 m2 rr 00 00 01 00 – 7F LEVEL TVA level
(=NRPN# 26)
41 m3 rr 00 00 01 00 – 7F ASSIGN GROUP NUMBER Non, 1 – 127
41 m4 rr 00 00 01 00 – 7F PANPOT -64 (RANDOM),
-63 (LEFT) – +63 (RIGHT)
(=NRPN# 28, except RANDOM)
41 m5 rr 00 00 01 00 – 7F REVERB SEND LEVEL 0.0 – 1.0
Multiplicand of the part reverb level
(=NRPN# 29)
41 m6 rr 00 00 01 00 – 7F CHORUS SEND LEVEL 0.0 – 1.0
Multiplicand of the part chorus level
(=NRPN# 30)
41 m7 rr 00 00 01 00 – 01 Rx. NOTE OFF OFF/ON
41 m8 rr 00 00 01 00 – 01 Rx. NOTE ON OFF/ON
41 m9 rr 00 00 01 00 – 7F DELAY SEND LEVEL 0.0 – 1.0
Multiplicand of the part delay level
(=NRPN# 31)
* When the Drum Set is changed, DRUM SETUP PARAMETER values will all be initialized.
* It is not possible to simultaneously use both Chorus Send Level and Delay Send Level for a single Drum Instrument.
