Roland VersaCamm SP-300V User Manual

56
3-4 Replacing Consumable Parts
Chapter 3 Maintenance and Adjustment
Replacing the Blade
If the blade becomes dull, replace it with the included replacement blade.
CAUTION
Be sure to perform operations as specified by these instructions, and never touch
any area not specified in the instructions.
Sudden movement of the machine may cause injury.
CAUTION
Do not touch the tip of the blade with your fingers.
Doing so may result in injury.
Procedure
➊
Enter the blade replacement mode.
Press
.
Press
several times.
Press
.
➋
Preparations are complete when this screen appears.
➌
Open the front cover and remove the blade holder.
➍
Remove the old blade.
➎
Install a new blade.
FINISHED?
MENU
REPLACE KNIFE
Loosen the screw.
Blade holder
New blade
Pin
Blade holder
Blade holder
Old blade
Press this pin

Roland VersaCamm SP-300V Specifications

General

Resolution	Up to 1440 dpi
Connectivity	USB
Print Technology	Piezoelectric Inkjet
Media Handling	Roll-fed
Ink Colors	Cyan, Magenta, Yellow, Black
Media Thickness	Max. 1.0 mm (39 mil) with liner
Media Types	Vinyl, banner, paper, film
Power Requirements	AC 100 to 120 V ±10 %, 50/60 Hz
Operating Environment	Temperature: 20-32°C, Humidity: 35-80% (non-condensing)
