Roland VersaUV LEF2-300 User Manual

If the print-head carriage stops over the at table, take acon immediately to prevent the heads from drying out.
What to Do First
Switch the sub power o and then back on again. If the print heads move to the home posion (inside the panel
cover), it means the operaon has ended successfully.
If the print heads sll do not move
Try switching o the main power, then switching on the main power again, followed by the sub power.
If the Heads Sll Do Not Move
If the heads sll do not move, carry out the following emergency response measure, and then contact your au-
thorized Roland DG Corporaon dealer.
Procedure
1. Switch o the main power, and then open the front cover.
2. Gently move the print-head carriage to the home posion by hand.
Stopping at the place where the audible click is heard locks the print-head carriage in place.
3. Close the front cover.
The Print Heads Do Not Move
238 2. Machine Problems

Roland VersaUV LEF2-300 Specifications

General

Printing Technology	Piezo inkjet
Ink Configuration	CMYK + White + Clear
Ink Colors	Cyan, Magenta, Yellow, Black, White, Clear
Connectivity	USB 2.0, Ethernet
Maximum Print Width	780 mm
Maximum Media Width	800 mm
Print Resolution	1440 x 1440 dpi
Media Thickness	Up to 200 mm
Maximum Media Thickness	50 mm
Ink Type	UV Ink
Ink Droplet Size	Variable dot
Power Supply	100-240V AC, 50/60Hz
Power Requirements	100-240V AC, 50/60Hz
Power Consumption	600W
Dimensions	1, 318 (W) x 983 (D) x 705 (H) mm 51.9 (W) x 38.7 (D) x 27.8 (H) in.
Dimensions (W x D x H)	1190 x 940 x 290 mm
Weight	128 kg
