Roland VersaUV LEF2-300 User Manual

Step 4: Reinstalling the Machine
Procedure
1. Once the preparaons are complete, move the machine with as lile delay as possible.
2. Reinstall the printer immediately, and then remove the retainer securing the print heads and at table in place.
For storage, aach retainer A ( ) and retainer B ( ) using the retaining screws ( ).
3. Turn on the main power switch.
IMPORTANT
To prevent the print heads from being damaged, move the machine with as lile delay as possible and switch on the main
power as soon as possible aer moving the machine. To install the machine again, follow the procedure in the Setup Guide.
4. Press the sub power buon.
Moving the Unit
266 2. Operations When Moving the Unit

Roland VersaUV LEF2-300 Specifications

General

Printing Technology	Piezo inkjet
Ink Configuration	CMYK + White + Clear
Ink Colors	Cyan, Magenta, Yellow, Black, White, Clear
Connectivity	USB 2.0, Ethernet
Maximum Print Width	780 mm
Maximum Media Width	800 mm
Print Resolution	1440 x 1440 dpi
Media Thickness	Up to 200 mm
Maximum Media Thickness	50 mm
Ink Type	UV Ink
Ink Droplet Size	Variable dot
Power Supply	100-240V AC, 50/60Hz
Power Requirements	100-240V AC, 50/60Hz
Power Consumption	600W
Dimensions	1, 318 (W) x 983 (D) x 705 (H) mm 51.9 (W) x 38.7 (D) x 27.8 (H) in.
Dimensions (W x D x H)	1190 x 940 x 290 mm
Weight	128 kg
