Rosco RB48 - Strike-Off Blade

Parts Book 6. 94 ROSCO - A LeeBoy Company
ITEM PART NO. QTY DESCRIPTION
RB48 BROOM
REF.
REV.
OTHER OPTIONAL EQUIPMENT - STRIKE-OFF BLADE
28753 STRIKE OFF BLADE
1 .............. 28740............ 1.00 ............... MOUNT,W/M,SNOW PLOW
2 .............. 28718............ 1.00 ............... BRACKET,W/M,FRONT
3 .............. 28726............ 1.00 ............... CONTROL BOX,SNOW PLOW
4 .............. 38224-26....... 2.00 ............... HYDRAULIC CYLINDER
5 .............. 38548............ 1.00 ............... CYL,HYD,2.0X8.0
N/S .......... 38546-01............................... SEAL KIT,HYD CYL,2BX1.12R
6 .............. 38224-01....... 1.00 ............... BLADE(7’6"STANDARD DUTY)
7 .............. 38224-32....... 3.00 ............... TRIP SPRING
8 .............. 38814............ 1.00 ............... MANIFOLD,HYD,2 STA,D03 (Detail Following)
N/S .......... 37647-01............................... COIL,SOLENOID 12V,BOSCH DO3
N/S .......... 37647-04............................... SEAL KIT,VALVE,BOSCH DO3
9 .............. 28492............ 2.00 ............... MOUNT,VALVE BLOCK
10 ............ 38983 ............ 1.00 ............... HOSE KIT,RB48,BOSS PLOW (Detail Following)
11 ............ 38641 ............ 1.00 ............... VLV,CHECK,06MJ,20 PSI CRACK
13 ............ 28719 ............ 1.00 ............... FRAME,W/M,PLOW LIFT
14 ............ 38961 ............ 1.00 ............... SWITCH,TOG,DPDT,3POS,MOM,DETEN
15 ............ 37516 ............ 1.00 ............... SWITCH,TOGGLE,SPDT,3-POS,MOM
16 ............ 80147 ............ 8.00 ............... WASHER,TYPE A PLAIN,.750
17 ............ 80357 ............ 4.00 ............... NUT,FLEXLOC,.750-10,FULL,LT
18 ............ 71680 ............ 2.00 ............... CSHH,.625-11X6.00,GR5
19 ............ 71683 ............ 2.00 ............... CSHH,.625-11X4.00,GR5
20 ............ 28758 ............ 1.00 ............... PIVOT PIN,W/M
21 ............ 80336 ............ 1.00 ............... COTTER PIN,.188X1.50
22 ............ 80150 ............ 1.00 ............... WASHER,TYPE A PLAIN,1.125
23 ............ 28717 ............ 1.00 ............... LIFT MOUNT,W/M
24 ............ 28781 ............ 2.00 ............... PIN,1.00X2.00 W/HOLES
25 ............ 71645 ............ 2.00 ............... CSHH,.750-10X3.50,GR5
26 ............ 80144 ............ 24.00 ............. WASHER,TYPE A PLAIN,.500
27 ............ 80164 ............ 12.00 ............. WASHER,SPLIT LOCK,.500
28 ............ 80040 ............ 12.00 ............. NUT,HEX,.500-13
29 ............ 80838 ............ 1.00 ............... CSHH,.750-10X4.50,GR5
30 ............ 36544 ............ 2.00 ............... HAIR PIN COTTER,7GA(.177)
31 ............ 80186 ............ 12.00 ............. CSHH,.500-13X1.75,GR5
32 ............ 38967 ............ 3.00 ............... EYE BOLT,.625-11X1.75X1.38ID
33 ............80356 ............ 6.00 ............... NUT,FLEXLOC,.625-11,FULL,LT
34 ............80146 ............ 9.00 ............... WASHER,TYPE A PLAIN,.625
39 ............ 38224-03....... .00 ................. CUTTING EDGE(7’6" STD DUTY)
40 ............ 38224-05....... 2.00 ............... PLOW SHOE ASSY
41 ............ 28755 ............ 1.00 ............... WIRE HARNESS,SNOW PLOW
43 ............ 80208 ............ 4.00 ............... CSHH,.312-18X1.00,GR5
44 ............ 80161 ............ 4.00 ............... WASHER,SPLIT LOCK,.312
45 ............ 80141 ............ 8.00 ............... WASHER,TYPE A PLAIN,.312
46 ............ 80037 ............ 4.00 ............... NUT,HEX,.312-18
47 ............ 28949 ............ 2.00 ............... CLEVIS PIN,3.50,MODIFIED
48 ............ 28948 ............ 1.00 ............... LOCK,HYD CYLINDER
49 ............ 80706 ............ 8.00 ............... WASHER,SAE PLAIN,1.000
50 ............ 38959 ............ 2.00 ............... DECAL,CONTROL BOX,SNOW PLOW
28753
D
