Rosco RB48 - Operators Deck

3.3
OperationROSCO - A LeeBoy Company
OPERATION
RB48 BROOM
1. Joystick with Brush Control Switches
and Transmission Control Selector Lever
2. Park/Emergency Brake Lever
3. Engine Throttle
4. Speed Selector Switch
5. Service Brake Pedal
6. Steering Wheel
7. Brush Drive Lever
8. Operators Seat
9. Brush Down Pressure Control
Figure 3-A
Operators Deck
6
2
5
1
3
9
7
4
