RB48 BROOM
4.11ROSCO - A LeeBoy Company
Maintenance
MAINTENANCE
Figure 4-G
Fuse Replacement Sizes
Figure 4-F
Fuse Panel Location
ELECTRICAL MAINTENANCE
The ROSCO Broom's electrical system is protected from overload damage by fuses. Should an
electrical component fail to operate, check the fuse panel first to make sure that a fuse is not
blown. The fuse panel is located in the front of the instrument panel directly in front of the
operator's seat. See Figure 4-F. Refer to Figure 4-G for replacement fuse sizes. Fuses that
blow may be replaced but will continue to blow until the cause of the overload is found and
corrected.
Always replace a blown fuse with the same rating as specified. Never replace with a
higher amperage rating. Severe wiring damage and possible fire could result.
