Rosco RB48 - Frame Assembly

Parts Book 6. 30 ROSCO - A LeeBoy Company
ITEM PART NO. QTY DESCRIPTION
RB48 BROOM
REF.
REV.
29084
0
FRAME ASSEMBLY
1 .............. 29027............ 1.00 ............... GEARBOX,MOUNT,W/M
3 .............. 29043............ 1.00 ............... FRONT AXLE ASSEMBLY (See Detail Following)
4 .............. 29171............ 1.00 ............... FRAME W/M,RB48B
5 .............. 33137............ 4.00 ............... CSHH,.750-10X2.50,GR5
6 .............. 33799............ 2.00 ............... TIRE VALVE,TUBELESS,.453,1.25
7 .............. 39025............ 1.00 ............... AXLE,REAR,FORD E150
Contact your Ford Dealer or local parts-supply store for replacement parts on this axle (V710F).
8 .............. 35330 ............ 1.00 ............... MOTOR,HYD,M46 VAR,2.8 CIR
9 .............. 35338............ 1.00 ............... GEARBOX B PAD 15T 4.533 RATIO (Detail Following)
10 ............ 35339 ............ 4.00 ............... U-BOLT,AXLE MOUNT
11 ............ 35342 ............ 2.00 ............... TIRE,RADIAL,ST225/75-R15,C
12 ............ 35603 ............ 1.00 ............... DRIVESHAFT (See Detail Following)
13 ............ 39027 ............ 2.00 ............... WHEEL,15X6.5 HOLE,5.5BC,FORD
14 ............ 6524.............. 10.00 ............. NUT,WHEEL,50-20
15 ............ 71627 ............ 1.00 ............... CSHH,.500-13X1.50,GR5
16 ............ 71631 ............ 1.00 ............... CSHH,.500-20X1.75,GR5 NF HT
17 ............ 80356 ............ 8.00 ............... NUT,FLEXLOC,.625-11,FULL,LT
18 ............ 80043 ............ 4.00 ............... NUT,HEX,.750-10
19 ............ 80147 ............ 4.00 ............... WASHER,TYPE A PLAIN,.750
20 ............ 80164 ............ 3.00 ............... WASHER,SPLIT LOCK,.500
21 ............ 81201 ............ 8.00 ............... WASHER,SAE,HARDENED,.625
22 ............ 80168 ............ 4.00 ............... WASHER,SPLIT LOCK,.750
23 ............ 80352 ............ 1.00 ............... NUT,FLEXLOC,.375-16,FULL,LT
24 ............ 80484 ............ 4.00 ............... WASHER,SPLIT LOCK,M12
25 ............ 27791 ............ 1.00 ............... HUB ASSY,WITH OUT BRAKES (See Detail Following)
26 ............ 81009 ............ 4.00 ............... CSHH,M12X1.75X30,CL8.8
27 ............ 81010 ............ 3.00 ............... CSHH,.312-18X4.00,GR8
28 ............ 81048 ............ 1.00 ............... CSHH,.375-16X3.00,GR8
29 ............ 010990739 .... 1.00 ............... KEY,SQ,.375X1.625
32 ............ 81141 ............ 4.00 ............... WASHER,SAE,HARDENED,.500
33 ............ 71634 ............ 1.00 ............... CSHH,.500-20X2.00,GR5
34 ............ 38620 ............ .80 ................. WIRE,MECHANICS,16.5 GA
