Ross NK-16 - T-Bus RJ-45 Connector

6–6 • Appendix A: Connectors and Pinouts NK Series User Guide (1.0)
Figure 6.12 Pinouts for DB-9 Connections on the NK-M16 and NK-M32 Machine Control Routers
GPI Alarm (NK-64 & NK-72 Models only)
Figure 6.13 shows the 3-way Phoenix connector on the rear of the NK-64 and NK-72 routers which is used to
connect GPI alarms.
Figure 6.13 3-way Phoenix Connector for GPI Alarms
T-Bus RJ-45 Connector
Figure 6.14 shows the RJ-45 connector port for the T-Bus control system.
Figure 6.14 RJ-45 Connector port for the T-Bus Control System
1
2
3
4
5
6
7
8
9
PIN MASTER SLAVE
1
2
6
7
3
8
4
9
5
GND
GND
GND
GND
GND
GND
Tx-
Tx-
Tx+
Tx+
Rx-
Rx+
Rx-
Rx+
DB-9 Male
(External View)
GND
+5V
Current limited to 15mA
Alarm / GPI
12345678
GND
Phantom Powe
r
+14.4V RCP
Tx/RxTx/Rx
+ RS-485 - RS-485
RJ-45 Female
(External View)
