AES/EBU Digital Audio Level
The AES/EBU level conforms to AES/EBU standards in digital audio streaming.
The NK-D64 is available in 75 Ω BNC models or optional 110 Ω DB-25 models.
Table 3.21 Outputs
SDI Video
Level
Multi-Definition Video
Level
NK-3G72
Connection 75 Ω BNC 75 Ω BNC 75 Ω BNC
Clocking Non-relocking Non-reclocking Reclocking
Return Loss >22 dB 15 dB 15 dB
Level 800 mV p-p 800 mV p-p 800 mV p-p
Table 3.22 Performance
SDI Video
Level
Multi-Definition Video
Level
NK-3G72
Jitter < 370 ps (.09 UI) < 0.2 UI < 0.2 UI
Data Rates 143 Mb/s to 540 Mb/s 143 Mb/s to 1.485 Gb/s 143 Mb/s to 3 Gb/s
Overshoot < 10% < 10 % < 10 %
Rise Time
–
Selectable SD/HD rise
time via on-board DIP
switches
Auto SD/HD
Table 3.23 General
SDI Video
Level
Multi-Definition Video
Level
NK-3G72
Partitioning Up to 8 partitions with
independent level
assignment
Up to 8 partitions with
independent level
assignment
Up to 8 partitions with
independent level
assignment
Configuration Phoenix or web browser
via NK-IPS
Phoenix or web browser
via NK-IPS
Phoenix or web browser
via NK-IPS
Dimensions 3 RU x 120 mm deep 3 RU x 120 mm deep 3 RU x 120 mm deep
Power Supply +15 V DC +15 V DC +15 V DC
