4–14 • Configuration NK Series User Guide (1.0)
Control Panels can be linked together if they have the same address and a different panel link address (that is not 0).
Linked panels behave exactly as if they were one larger panel with the exception that macros can not be appended
or added across panels. The panels communicate using the T-Bus protocol with support for collision detection.
Each key can be assigned a function, with up to 3 parameters (Default, Shift1 and Shift2). This function will be
called when that switch is pressed. The key functions are:
RCP-NK1 Configuration
The Device Properties page, accessible through the NK-IPS, allows users to configure interface and key
assignments for RCP-NK1 control panels, as well as having the unique ability to assign names and brief
descriptions for the devices themselves.
For More Information on...
• how to query devices, and use of the NK-IPS, refer to the NK-IPS Internet Protocol Server User Guide.
• how to configure RCP-NK1 via Phoenix, refer to the Phoenix Online Help Guide.
DESTINATION Changes the destination that the panel is controlling. If the DESTINATION KEY is not
active, the default value is selected. When the DESTINATION KEY has been selected
first, the relative destination is selected.
SOURCE Switches the input using the current destination and level pattern. If the SOURCE KEY
is not active, the default value is switched. When the SOURCE KEY has been selected
first, the relative source is switched.
CROSSPOINT Switches the input, output and level/breakaway associated with this key.
LEVEL Toggles this level number from the current level pattern.
BREAKAWAY Selects a preconfigured breakaway level pattern.
BREAKAWAY STEP Steps through breakaways.
MACRO Records key events that can be replayed later.
PROTECT The PROTECT key attempts to protect the currently selected output/level pair.
TAKE The TAKE key confirms input key events. The user sets up a switch, and presses the
TAKE key to activate the switch.
CHOP Alternates between the last two selected inputs.
SHIFT Changes the source or destination page of the panel.
DEASSIGN Allows users to reset a destination assignment.
MACHINE CONTROL Toggles on/off RS-422 Machine Control for reciprocal switching.
PANEL LOCK Locks the panel from all switches or function key operation.
UNASSIGNED Key is not assigned any function or value.
