4–2 • Configuration NK Series User Guide (1.0)
Keys that are not available on the factory default configuration of the RCP-NK1, but may be assigned and
configured via the NK-IPS, are listed below.
NK Series Router Levels Default
The factory default configuration breakaway and levels for the NK routers is as depicted in Table 4.1.
DESTINATION SHIFT Changes the destination page of the panel
SOURCE SHIFT Changes the source page of the panel.
LEVEL Toggles the specified level number from the current level pattern.
Four Level keys are available on the factory default configuration: Level 2 - SDI Video
Level 5 - Analog Video Level 6 - Analog Audio (Left channel) Level 7 - Analog Audio
(Right channel)
MACRO Records key press events that can be replayed later.
BREAKAWAY Selects a preconfigured breakaway level pattern.
CROSSPOINT Switches the input, output and level/breakaway associated with this key.
BREAKAWAY STEP Steps through breakaways.
PROTECT Protects the currently selected output/level pair. The PROTECT key also activates the
panel lock function.
TAKE Confirms input key events. After a switch is set up, press the TAKE key to activates the
switch.
CHOP Alternates between the last two selected inputs.
DEASSIGN Allows users to reset a destination assignment.
MACHINE CONTROL
KEY
Toggles on/off RS-422 Machine Control reciprocal switching.
PANEL LOCK Activates the panel lock function, for environments where a PROTECT KEY is not
required.
UNASSIGNED Key is not assigned any function or value.
Table 4.1 Configuration Breakaway and Levels for the NK Routers
3G/HD/SD
Video
SD Video
AES/EBU
Audio (1)
AES/EBU
Audio (2)
Analog
Video
Analog
Audio (Left)
Analog
Audio
(Right)
Machine
Control
Default
99999999
Level 1
9
Level 2
9
Level 3
9
Level 4
9
Level 5
9
Level 6
9
Level 7
9
Level 8
9
