Input and Output Connections
AC-825IP Hardware Installation and User Guide 35
Scenario Setting
Two Readers per Door
Door 1 – IN 1B
Door 2 – IN 3B
Door 3 – IN 5B
One Reader per Door
Door 1 – IN 1B
Door 2 – IN 2B
Door 3 – IN 3B
Door 4 – IN 4B
Door 5 – IN 5B
Door 6 – IN 6B
Two Readers per Door
Door 4 – IN 1D
Door 5 – IN 3D
One Reader per Door
Door 7 – IN 1D
Door 8 – IN 2D
Door 9 – IN 3D
Door 10 – IN 4D
4.2.3 General Purpose Inputs
These are free inputs that can be used for various functions. The following
should be defined:
Scenario Setting
Two Readers per Door
IN 2A
IN 2B
IN 4A
IN 4B
IN 6A
IN 6B
One Reader per Door
(no general purpose
inputs available)
General purpose inputs are suitable for most uses. For example, they might be
used to detect tampering, to activate trouble signals, or to monitor a power
management board failure.
General purpose inputs functions when using S-805 or D-805:
Unit Expansions
S-805
P-805
IN 1S to IN 16S
IN 1P to IN 16P
D-805 IN 2C
IN 2D
IN 4C
IN 4D
