Introduction
AC-825IP Hardware Installation and User Guide 9
The AC-825IP platform consists of the following components:
AC-825IP networked access controller
ME-1515 metal enclosure with a detachable illumination bar
Up to 4 A power management board
VAC/VDC power switch
Terminal block removal tool
12 x 2.2 kΩ and 12 x 8.2 kΩ resistors for the supervised inputs
1.1 Open Supervised Device Protocol
OSDP allows connecting control panels with various peripheral devices (card
readers, control panels, and other security management systems) while
unlocking the potential of the onboard computing resources within the
system.
Each panel can connect to up to two readers via OSDP.
Any device that is connected to the AC-825IP panel via RS-485 must have a
unique serial address.
1.2 AxTraxNG
The AxTraxNG software is custom designed to set up, manage, and supervise
all aspects of an access controller’s network.
It offers the following capabilities:
1.2.1 Client-Server Structure
AxTraxNG operates through a dedicated AxTraxNG server computer, which
communicates with the access control panels and their expansions to serve an
unlimited number of network clients.
The server also runs the system's SQL database, which contains settings and
definitions for access control across the entire facility. System users can define
new users and credentials, and control access permissions. The system includes
tools for database backup, input, and export of previous configurations and
automatic backup on a periodic basis.
AxTraxNG supports all panel types and offers scalability and flexibility in
addition to a range of advanced control features.
