1. Introduction
The AC-825IP is an advanced networked access controller and is the backbone
of a medium-scale to high-scale security system that can handle up to 100,000
users and 500,000 events.
Each AC-825IP access control unit (ACU) supports up to 6 doors (In/Out), each
with 2 inputs and 1 output, and includes four additional auxiliary inputs and
two auxiliary outputs.
The number of supported doors, inputs, and outputs can be increased by using
the onboard 10-pin expansion slot to connect any of the following expansion
boards:
 R-805 – 16 outputs
 S-805 – 16 inputs
 D-805 – 4-door expansion
 P-805 – 16 inputs and 8 outputs
The system currently supports 12 extension boards via RS-485 with Open
Supervised Device Protocol (OSDP), of any kind, in addition to the expansion
board mounted on top of the AC-825IP panel.
Driven by Rosslare’s powerful, flexible and easy to use AxTraxNG™ software,
the system provides an ideal, modular and expandable solution for commercial
and institutional needs. It provides seamless integration with Rosslare's UL
Listed range of RFID proximity, PIN, Proximity & PIN, smart card, and biometric
readers with Rosslare’s selection of RFID credentials.
The AC-825IP is ready for installation with a mountable and lockable metal
enclosure (ME-1515) integrated with a switch, power management
board/charger, sounder, and control panel.
Using an onboard Ethernet TCP/IP, multiple local or remote site door
subnetworks can connect to the AxTraxNG Client/Server PC software running
on Microsoft
®
Windows
®
7/8 operating systems.
The onboard Ethernet TCP/IP was evaluated by UL as a standalone unit and is
used for programming use only.
