Rosslare AC-825IP User Manual

Technical Specifications
12 AC-825IP Hardware Installation and User Guide
MECHANICAL SPECIFICATIONS
Enclosure Dimensions
(H x W x D)
346 x 404 x 101 mm (13.6 x 15.9 x 4.0 in.)
Enclosure Weight*
4.6 kg (10.1 lb)
PCBA Dimensions (H x W)
224 x 164 mm (8.8 x 6.46 in.)
PCBA Weight 400 g (14.1 oz)
Backup Battery Dimensions
(H x W x D)
95 x 150 x 65 mm (3.7 x 5.9 x 2.6 in.)
Fuse Dimensions (H x W) 20 x 5 mm (0.8 x 0.2 in.)
* For weight purposes, the ME-1515 enclosure includes the metal box, AC input, DC
output and LED bar.
2.2 Expansions for AC-825IP
Specification R-805 S-805 D-805 P-805
OPERATIONAL SPECIFICATIONS
Relays 5 A, Form-C 16 N/A 4 8
Supervised Inputs N/A 16 8 16
Readers (Wiegand format) N/A N/A 4 N/A
Readers (OSDP format) N/A N/A N/A N/A
Connectivity OSDP
ENVIRONMENTAL SPECIFICATIONS
Operating Temp. Range
-5°C to 50°C (23°F to 122°F)
Storage Temp. Range
-25°C to 50°C (-13°F to 122°F)
Operating Humidity
Range
0 to 85% (non-condensing)
MECHANICAL SPECIFICATIONS
Weight
230 g
(8.1 oz)
150 g
(5.3 oz)
200 g
(7.1 oz)
Dimensions (H x W x D)
178 x 87 x 30 mm (7.0 x 3.4 x 1.2 in.)

Rosslare AC-825IP Specifications

General

Brand	Rosslare
Model	AC-825IP
Category	Controller
Language	English
