AC-825IP Hardware Settings
40 AC-825IP Hardware Installation and User Guide
Connectors
Description Setup
Door6 Lock output (OUT 6)
Inputs Door1 Request-to-Exit (IN 1A)
Door monitor input (IN 1B)
Door2 Request-to-Exit (IN 2A)
Door monitor input (IN 2B)
Door3 Request-to-Exit (IN 3A)
Door monitor input (IN 3B)
Door4 Request-to-Exit (IN 4A)
Door monitor input (IN 4B)
Door5 Request-to-Exit (IN 5A)
Door monitor input (IN 5B)
Door6 Request-to-Exit (IN 6A)
Door monitor input (IN 6B)
Readers Reader1 (Door1 IN/OUT)
Reader2 (Door2 IN/OUT)
Reader3 (Door3 IN/OUT)
Reader4 (Door4 IN/OUT)
Reader5 (Door5 IN/OUT)
Reader6 (Door6 IN/OUT)
Two Readers per Door with 10 Readers (D-805):
Outputs Door1 Lock output (OUT 1)
Door2 Lock output (OUT 3)
Door3 Lock output (OUT 5)
Door4 Lock output (OUT 1D)
Door5 Lock output (OUT 3D)
Inputs Door1 Request-to-Exit (IN 1A)
Door1 monitor input (IN 1B)
Door2 Request-to-Exit (IN 3A)
Door2 monitor input (IN 3B)
Door3 Request-to-Exit (IN 5A)
Door3 monitor input (IN 5B)
Door4 Request-to-Exit (IN 1C)
Door4 monitor input (IN 1D)
Door5 Request-to-Exit (IN3C)
Door5 monitor input (IN3D)
Readers Reader1 (Door1 IN/OUT)
Reader2 (Door1 OUT/IN)
Reader3 (Door2 IN/OUT)
