User Manual - 9/32
IV. CONTROLLER FUNCTIONS
1. MAIN MENU
Block diagram – Controller main menu
2. OPERATION GLOBAL SYSTEM MODE MENU
Diagram – Operation global mode menu
This function enables the user to select the operation mode globally for the whole system.
Normal mode is used when you want the pre-set temperature to follow the selected operation mode for each single zone.
Holiday mode is used when you want to lower the temperature globally for all zones for a longer period, for example during your
holiday. Pre-set temperature can be changed in Zones > user settings > temperature settings. Default setting is 10°C.
Economy mode is used when you want to lower the temperature globally for all zones for a shorter period, for example during a
weekend where you are away from home.
Pre-set temperature can be changed in Zones > user settings > temperature settings. Default setting is 18°C.
Comfort mode is used when you want to raise the temperature globally for all zones for a shorter period, for example to overrule
a running timeschedule without having to change it.
Pre-set temperature can be changed in Zones > user settings > temperature settings. Default setting is 24°C.
