CK Standard and CKR Start Up Guide
2
CK – Valve Actuation 2
CK Mechanical Switch Mechanism – Switch Testing 3
Test feedback switches 3
CK Mechanical Switch Mechanism – Basic Settings 5
Set Torque Limits 5
Set Position Limits 6
CK Additional Indication Drive – Switch Testing 8
Test feedback switches 8
CK Additional Indication Drive – Basic Settings 10
Set Torque Limits 10
Set Position Limits 10
Setting Local Position Disc 12
Setting Intermediate Switches 14
Setting the POT 15
Setting the CPT 16
CK actuators have been developed with over 20 years
of experience in actuation solutions. Our valve actuation
products range from standard mechanical actuators to
advanced digital actuators with integral controls.
Rotork has an extensive product range catering for all
industries. Our actuation solutions deliver state-of-the-art
performance, value and reliability to the global valve industry.
We can help you through the process of product selection
and specification from the installation of a single actuator up
to complex system integration.
With an international network of offices and distributors we
can fully support customer and end user requirements. Over
1,000 service technicians are employed by our company,
partners and representatives, providing the necessary
worldwide infrastructure to fully support actuators in the field.
CK – Valve Actuation
Worldwide coverage
Our extensive international network enables us to think
globally and act locally when it comes to supporting our
customers. Rotork provides an efficient sales service, after
sales commissioning and maintenance support throughout
the life of the actuator.
Global manufacturing
Product reliability and integrity are priorities in CK product
development. Our quality control teams source components
from suppliers throughout the world to ensure our customers
always receive first class actuation solutions.
Customer support
Rotork provide service support solutions to maximise your
productivity and reduce your operational risk.
Information about this manual
The information and instructions included in this manual
are applicable for all CK Standard and CK
R actuators. For
information or instructions on other CK Range actuators
please visit www.rotork.com
Contents
Section Page Section Page
