Installation & Maintenance Instructions

7.0 Basic Setup

LOCAL

VIEW

OP LIM

LOCAL

OP LIM

LOCAL

EDIT

OP LIM

LOCAL

SAVED

EDIT

LOCAL

CL LIM

7.8 Set Open Limit of Travel

Press the DOWN arrow until the OP LIM menu is displayed.

Press ENTER to put the actuator in to EDIT Mode.

This will allow parameter changes to be made.

Use the UP and DOWN buttons to move the actuator output

drive to the required OPEN position.

Press ENTER and the new OPEN End of Travel Limit is saved to

the actuators memory.

THE OPEN END OF TRAVEL LIMIT IS SET.

Press CANCEL to go back to top level menu.

STEP 1

SELECT LOCAL

OPERATION

STEP 2

SET OUTPUT

THRUST

STEP 4

SET CLOSE LIMIT

OF TRAVEL

STEP 5

SET OPEN LIMIT

OF TRAVEL

STEP 6

CALIBRATE COMMAND

SIGNAL ZERO SETPOINT

STEP 7

CALIBRATE COMMAND

SIGNAL SPAN SETPOINT

STEP 3

SELECT ACTION AT END

OF TRAVEL (LIMIT OR FORCE)

STEP 8

DEADBAND

Fig 7.27 Close limit setting

Fig 7.28 Open limit setting

Fig 7.29 View open limit setting

Fig 7.30 Edit open limit position

Fig 7.31 Save new limit position
