6.0 Installation
6.1 Installing your Actuator
The following instructions must be followed and integrated
into your safety program when installing and using Rotork
products.
• Read and save all instructions prior to installing,
operating and servicing this product
• If you don’t understand any of the instructions contact
Rotork for clarification
• Follow all warnings, cautions and instructions marked on
and supplied with the product
• Inform and educate personnel in the proper installation,
operation and maintenance of the product
• Protection provided by the equipment may be impaired if
used in a manner not specified by Rotork
Install equipment as specified in Rotork installation
instructions and as per applicable local and national
codes of practice. Connect all products to the proper
electrical sources.
•
To ensure proper performance, use only qualified
personnel to install, operate, update and maintain the unit
• When replacement parts are required, ensure that the
qualified service technician uses only replacement parts
specified by Rotork
• Substitutions will invalidate any hazardous area
certification and may result in fire, electrical shock, other
hazards or improper operation
• Keep all product protective covers in place (except during
installation or maintenance by qualified personnel)
to prevent electrical shock, personal injury or damage
to equipment
• Operation of the actuator in an inappropriate fashion
may cause harm or damage to the unit or surrounding
equipment
The end user should take care when assessing the local
ambient temperature to take into account the heat from any
connecting pipe-work or inherent heat from process plant etc.
Tools & Equipment Required (General Guideline Only)
Top Cover Fixings - 8 mm Allen Wrench
Electrical Connections - Terminal Screw Driver
- Power Supply
Command & Feedback - 4 to 20 mA Command
source/meter
Actuator to Valve fixings - As required
