rotork CML Series User Manual

Keeping the World Flowing
41
10.0 Default Menu
10.2.4 Control Configuration Menu
PARAMETER DEFAULT VALUE
Control Algorithm Open loop
Input Dampening 0 seconds
Input Signal Loss Time out 0 seconds
Input Signal Loss Action Close
Input Signal Loss Position 50%
Input Signal Loss Low Level 3.6 mA
Input Signal Loss High Level 20.4 mA
TORQ O 100%
TORQ C 100%
CL ACT LIM
OP ACT LIM
10.2.5 Relays 1 & 2 Menu
PARAMETER DEFAULT VALUE
Relay 1 Config None
* Relay 1 Pos 25%
Relay 1 Form Energize on Condition
Relay 2 Config None
* Relay 2 Pos 75%
Relay 2 Form Energize on Condition
* Only shown when configured as Drive to Position (won’t be configured for position on default)
10.2.6 Split Range Menu
PARAMETER DEFAULT VALUE
Lower Range Value 4 mA
Upper Range Value 20 mA
CMD Below Split Range Action Disabled - no action
CMD Above Split Range Action Disabled - no action
10.2.7 Actuator Config Menu
PARAMETER DEFAULT VALUE
Actuator Type Set at Factory to match actuator build
Actuator Size Set at Factory to match actuator build
Encoder Initialization Set at Factory at middle of travel
10.2.8 UPS Menu
PARAMETER DEFAULT VALUE
Loss of Power Action Disabled - No action
Loss of Power Position 50%
Loss of Power Time out 0 Seconds
Loss of Power Speed 100%
Override Remote Control ON - Loss of power action overrides remote control
Override Local Control OFF - Local control overrides loss of power action
Override Local Stop Control OFF - Local Stop control overrides loss of power action
