Parameters
Publication PUB088-005-00_1017 69 of 84
Pakscan Modbus Data Base Information
Foundation Fieldbus FF
-
01 Installation manual
Parameter
No.
Data
Read /
Write
Value / Range
Default Value
‘PO’ contact S4
86
Function for Indication contact S5
R/W
Bit 0: 0-Normally
Open, 1 – normally
closed.
Bits 1 to 15:
See separate table
‘S contact functions’.
0001
87
Function for Indication contact S6
R/W
0003
88
Function for Indication contact S7
R/W
000D
89
Function for Indication contact S8
R/W
002B
90
Position trip when function set to
‘PO’ contact S5
R/W
0-100%, 0 to 0064 h
0001
91
Position trip when function set to
‘PO’ contact S6
R/W
0-100%, 0 to 0064 h
0001
92
Position trip when function set to
‘PO’ contact S7
R/W
0-100%, 0 to 0064 h
0001
93
Position trip when function set to
‘PO’ contact S8
R/W
0-100%, 0 to 0064 h
0001
94 - 96
For future use
R
0000
97
ESD direction
R/W
00: Close,
01: Open,
10: Stationary
11: Ignore ESD
0000
98
ESD contact
R/W
0: ESD break contact
1: ESD make contact
0000
99
ESD bypasses the actuator
interlocks
R/W
0: bypass disabled
1: bypass enabled
0000
100
ESD bypasses the Thermostat trip
R/W
0: bypass disabled
1: bypass enabled
0000
101
ESD bypasses Local stop
R/W
0: bypass disabled
1: bypass enabled
0000
102
Bits0 to 5 - reserved
Bit6 – Interlocks enable / disable
Bits7 to 15 - reserved
R
0: Interlocks Enabled
1:Interlocks Disabled
0001
103
Open limit position
R
-
001A0000
104
Interrupter timer start limit
R/W
0: Around close limit
1:Around open limit
0000
105
Interrupter timer off time
R/W
1-99secs, 0 to 0063h
0002
106
Interrupter timer on time
R/W
1-99secs, 0 to 0063h
0003
107
Interrupter timer activated when
opening if below xx%
R/W
0-100%, 0 to 0064 h
0028
108
Interrupter timer activated when
closing if below xx%
R/W
0-100%, 0 to 0064 h
002D
109
Bits0 to 4 - reserved
bit5 – Language
Bits6 to 15 - reserved
R
0: English
1: Alternative
language
0000
110
Reserved
R
-
0000
111
ID Main
R
16bytes ASCII
-
112
ID Locals
R
16bytes ASCII
-
113
ID Resolver
R
16bytes ASCII
-
114
ID Power
R
16bytes ASCII
-
