Handle
The handles are equipped with switches
and rollers to control Rototilt® functions
and base machine functions.
The standard version has 2 rollers and 7
switches in each handle.
There are 5 switches for the base
machine functions.
The handle functions are congured by
an authorised installer. Functions are
programmed according to the following
standard unless otherwise stated.
Left Handle
A Rotation
1 Option 1
D Extra 2
Right Handle
B Tilt
2 Option 2
C Extra/Grapple
Also see sticker and display
!
IMPORTANT - The base machine’s factor-installed
handles have been replaced with handles adapted
for ICS.
Carefully check the changed functions, for both the
base machine and Rototilt®.
Machine control
Machine control regulates the oil ow to
the hydraulic circuit for extra equipment
on the base machine. Movement of
the rollers in the handles affects the oil
ow in the machine's main valve via the
control unit.
The system has two different functions:
Rototilt® control
When the 8-pole connector on the stick is
connected, a ow is regulated parallel to
the valves on Rototilt ® and the hydraulic
ow is adjusted to this.
The ow runs in one direction only.
Regulation of extra hydraulics
When the base machine is run without
Rototilt ®, the control can be used to
regulate the oil ow in the machine circuit
for extra hydraulics.
The ow can be regulated in both
directions.
In this mode, the extra/grapple roller
regulates MP/HP2.
2200230_ _7225
