 Speckle Size: When the general mode is selected as the scanning mode, this
parameter will become ineffective; when the special mode is selected, this parameter will
become effective. The controller will control this parameter among 50%~99%.
The cutting and scanning parameters can’t exceed the limited ones in the
axle parameters. If so, the setting will become ineffective and the system
will automatically cover the parameters with the axle parameters.
（
3
）
Feeding parameters
 Before-feeding Time Lag: settable at 0~300s. The lagged time can facilitate user’s
feeding and picking on the feeding device.
 After-feeding Time Lag: settable at 0~9.9s. It can facilitate the feeding device
’
s
delaying in jarring after moving to the correct position and waiting for the 2
nd
work after the
feeding axle stands still completely.
 Progressive feeding: If this item is enabled, then the dummy array graph on Y
direction will run in the same position, running one line graph, the U axes moving one time to
feed, the moving length of U axes is the interval of the two lines graph on Y direction.
 Progressive feeding repay: Because of the imprecision of U axes
’
moving, there can
set a value to repay the interval of the two lines graph on Y direction.
（
4
）
Reset parameters
 Reset Speed: it means the speed of X/Y-axle linkage reset to the origin.
 X axle start-up reset(Auto home)
 Y axle start-up reset(Auto home)
 Z axle start-up reset(Auto home)
 U axle start-up reset(Auto home)
You can select
“
Yes
”
or
“
No
”
in the field of the above four parameters, which is used to confirm
whether each axle can be reset on the startup.
（
4
）
Go scale parameters
 Go scale Mode: “Blanked Bordering” means idling to start border preview; “Outputted
Border Cutting” can manually cut off the well-processed figure; “4-corner Dotting” means to
emit the light at four corner points of the frame to make a point and turn off light. The size and
position of this figure can be checked intuitively through the four points. The bordering speed is
the speed value set on the keyboard when the system is idle. For light output, its
minimum/maximum power is the corresponding value set on the keyboard when the system is
