idle (The lasering power on the 4-corner dotting means the well-set maximum power).
Go scale Blank: It means whether to extend a certain length outside the actual frame
of the figure on the preview/cutting of frame.
If the frame crosses the border, the interface will prompt it. If the Enter
key is pressed at this time, the system will cut the border at the
maximum/minimum coordinates first, and then border the figure. This
bordering can be given up.
Array Mode: Two-way array or one-way array can be selected. Two-way array means
the to-and-fro cutting of array in sequence; one-way array means the cutting of array from one
direction to another. On selecting one-way array, the elements of each array are the same in
action mode and completely uniform in action fluency, which takes a little more time than
two-way array. Two-way array is the default option.
Back Position: The origin (the relative origin) and the machine’s absolute origin can be
selected. This parameter decides the parking position of laser head after each work.
Focus Setting: it means the distance from the focal point of laser head lens to Z-axle
origin. When there is no automatic focusing function, this parameter becomes invalid.
Material thickness: Thickness of the object to be processed.
Non-contact focusing: When YES is selected, the focus mode is non-contact focus,
otherwise it is contact focus mode. This parameter defaults to contact focus mode.
The above three parameters are used to set the auto focus function. The auto focus mode
can be divided into two modes: contact focus and non-contact focus. Each mode is divided into
two modes. The autofocus function is done by the D axis.
Mode 1: The D-axis directly drives the laser head to move downward until the laser head
touches the surface of the material. At this time, the controller considers the position to be the
origin position of the D-axis, and then the D-axis moves to the opposite direction by a certain
distance. The distance is the focal length value in the parameter settings. In this mode, the
material thickness parameter is invalid.
Mode 2: The D-axis drive platform moves upward until the material touches the laser head.
At this time, the controller considers the position to be the origin position of the D-axis, and
then the D-axis moves to the opposite direction by a certain distance, which is the parameter.
The focus value in the settings. In this mode, the material thickness parameter is invalid.
