Web-based Configuration Guide Fast Internet Access
10
(4) Configure the Internet connection type according to requirements of the local Internet Service Provider (ISP).
Otherwise, the Internet access may fail due to improper configuration. You are advised to contact your local
ISP to confirm the Internet connection type:
Figure out whether the Internet connection type is PPPoE, DHCP mode, or static IP address mode.
In the PPPoE mode, a username, a password, and possibly a service name are needed.
In the static IP address mode, an IP address, a subnet mask, a gateway, and a DNS server need to be
configured.
In the DHCP mode, DHCP automatically assigns network parameters without manual intervention.
2.4.2 Configuration Steps
1. Configuring the Internet Type
Click Configure and select the Internet type confirmed with the ISP.
DHCP: The device detects whether it can obtain an IP address via DHCP by default. If the device connects
to the Internet successfully, you can click Next without entering an account.
Caution
● If the primary router assigns an IP address from the 192.168.110.0 network to the mesh repeater, the
mesh repeater will change the IP address of its LAN port to 192.168.111.1 automatically. Mistaking the
mesh repeater for the primary router and changing its configuration may cause a network disconnection.
You are advised to refer to the model and Wi-Fi information on the homepage.
PPPoE: Click PPPoE, and enter the username, password, and service name. Click Next.
Static IP: Enter the IP address, subnet mask, gateway, and DNS server, and click Next.
