S-TEC Fifty Five X - Roll Axis Limits; Pitch Axis Limits

3rd Ed. Sep 30, 06 4-3
S–TEC
4.1 Roll Axis Limits
Turn Rate
Piston A/C:
90% Standard Rate Turn (HDG, NAV, NAV APR, REV, REV APR, CWS Modes)
Turboprop A/C:
75% Standard Rate Turn (HDG, NAV, NAV APR, REV, REV APR, CWS Modes)
All A/C:
130% Standard Rate Turn (NAV GPSS Mode) for Programmer/Computers with
Hardware Mod Code AM and below.
90% Standard Rate Turn (NAV GPSS Mode) for Programmer/Computers with
Hardware Mod Code AN and above.
4.2 Pitch Axis Limits
Altitude
32,000 FT
Vertical Force Due to Acceleration
0.60 g
Vertical Speed
1600 FPM Climbing or Descending
Modes
A pitch mode (ALT, VS, GS) can only be engaged after a roll mode (HDG, NAV,
NAV APR, REV, REV APR, NAV GPSS) has been engaged.
2nd Rev. Apr 15, 07
