Saeco Classic - Disassembling Doser Switch

9. DISASSEMBLY ROYAL
Seite 6/20 REV.4 SEPT.2003 Saeco International Group
4. Disassembling doser switch
a) Push the powder coffee compartment in direction of the arrow (1) and lift it
(2). Carefully pull out the two rubber holders (3).
Fig. 9
b) Disconnect the switch. Lift the doser switch using a screwdriver (1) and push
it out of ist fitting (2).
Fig. 10
1
2
3
2
1
