Saeco Classic - Service Programme (Royal Classic); Test Mode

ROYAL 5. SERVICE PROGRAMME
Saeco International Group REV.4 SEPT.2003 Page 1/24
1. Service programme (Royal Classic):
1.1. Test mode
Access: Access the service mode by turning on the machine and simultaneously pressing the
Coffee and steam buttons.
Press Coffee and Steam buttons.
Various test functions can be activated in the service mode by activating either the coffee or steam
buttons in conjunction with various coffee quantity settings.
Programme table
Function Button
Control
setting
LED Indicator
Pump/Turbine *
Coffee Fault LED
(flow meter pulses)
Brewing unit
(Gearmotor)
Steam Coffee LED
Gear switch
(brewing setting)
Heating Coffee
Brewing unit
(Gearmotor)
Steam Coffee LED
Gear switch
(home position)
Dosing magnet Coffee
Grinder
Steam Steam LED
Doser full
HWS microswitch
Steam LED
* The HWS valve must be open.
The current boiler temperature can be read in service mode by pressing the coffee and steam buttons at
the same time.
Each combination of LEDs provides an indication on the current boiler temperature
(see table below).
Temperature table
Temperature
status
Coffee LED Steam LED Fault LED
T ≤ 94ºC
X
T = 95ºC
X X
T = 96ºC
X
T = 97ºC
X X
T ≥ 98ºC
X
