ROYAL 9. DISASSEMBLY
Saeco International Group REV.4 SEPT.2003 Seite 13/20
8. Disassembling the instantaneous water heater
a) Remove the hose clip of the HWS-valve (1) and the instantaneous water
heater (2) and remove the Water hose.
Fig. 21
b) Remove the two fixing screws (1) of the instantaneous water heater (new
version / boiler J is fixed with 3 screws).
Fig. 22
