Page 4 / 17 Saeco Internationa Group
05 SERVICE MODALITY TALEA / ODEA - LINE
Function level/display Key Function Display/description
*Test* M3 Test: El.valve/Adjust,Test Dosage quantity/Pump
Flowmeter
*Test* M3 xx yy
z (8)
Menu Elctronic valve z: Ev Brew (the electro valve
opens)
8: Sensor bean cover (closed)
*Test* M3
Setup Aroma (imp) tt
Enter: Coffee
Adjust: Ring
Store: Coffee
Dosage quantity -
start position
tt: 60 - 150 dosage quantity start
position
(From Version 02.00.08
autodose)
*Test* M3 xx yy
u (8)
Aroma Dosage quantity
for the grinder
test
u: 1 = mild start position -10%
u: 2 = medium start position
u: 3 = strong start position +10%
*Test* M3 (F) xx yy
Grinder (8) vv ww
Steam Grinder on Grinds the dosage quantity
resulting from the start position
and u (1,2,3)
vv: Number of pulses
ww: Pulses/sec.
F: Failed (low on beans)
S: Successful (beans detected)
xx: Factory parameters
yy: Factory parameters
*Test* M3 xx yy
Flowmetre (pulses/s) ff
Hot water Pump on ff: Number of pulses/sec (approx.
14-17)
*Test* M4 Test: Continuous-fl ow heater / cup warmer /
temperature display
*Test* M4 4
Cup Heater
Menu Cup warmer Cup warmer heats up
- No temperature display
4: Key test (menu key)
*Test* M4 3
Heater
Aroma Continuous-fl ow
heater
Continuous-fl ow heater heats up
Temperature quantity with hot
water key
3: Key test (Aroma key)
*Test* M4 2
Boiler temperature tt
Hot water Temp. display tt: Boiler temperature
2: Key test (hot water key)
*Test* M4 2
Boiler Temperature tt
Hot water /
steam valve -
Valve open +
coffee key
Let steam out
tt: Boiler temperature
Heats up to 110°C after completing
the display pass!!
*Test* M5 Test: Cup lift (Ring Plus only)
*Test* M5 4 (67)
Cuplift Position
Menu Upwards
movement
G: Upper end switch activated
4: Key test (menu key)
6: Cup lift UP sensor
7: Cup lift DOWN sensor
*Test* M5 3 (67)
Cuplift Position
Aroma Downwards
movement
F: Bottom end switch activated
3: Key test (Aroma key)
6: Cup lift UP sensor
7: Cup lift DOWN sensor
*Test* M6 Adjustment: LCD Contrast
*Test* M6 time
LCD Contrast xx%
Coffee Adjustment (ring) xx: 0 - 100
To Next Page
