Saeco TALEA - Coffee Grinder

Saeco International Group Page 9 / 13
TALEA / ODEA - LINE 07 DISASSEMBLY
To disassemble the coffee grinder
7.10. Coffee grinder
1
2
Fig. 1
• Remove the screws shown.
• Loosen the motor mounting bracket
(A).
• Remove the cover.
Fig. 2
1. Loosen the cable tie.
Fig. 3
• When installing, take care that the
spring is fi tted correctly in the centre
of the coffee grinder axis.
A
3
