Saeco TALEA - Cup Lift

Page 12 / 13 Saeco International Group
07 DISASSEMBLY TALEA / ODEA - LINE
To disassemble the electrical cup lift
7.13. Cup lift
Fig. 1
• Remove the screws shown.
• Loosen the motor mounting bracket
(A).
• Remove the cover.
Fig. 2
1. Loosen the cable tie.
Fig. 3
• When installing, take care that the
spring is fi tted correctly in the centre
of the coffee grinder axis.
1
2
3
