Saeco International Group
Page 13 / 13
T
ALEA / ODEA - LINE
07 DISASSEMBL
Y
To disassemble the electrical cup lift
Fig. 1
•
Remove the scr
ews shown.
Fig. 2
•
Remove the securing clips.
•
Loosen the sensor cable.
•
Unhinge the cup lift.
2
1
75
77
