DOCUMENT SSE-0000077399-01 - VERSION 1.0 - MAY 2010 11
S
AGEM SÉCURITÉ DOCUMENT - REPRODUCTION AND DISCLOSURE PROHIBITED
MORPHOACCESS® J SERIES – User Guide Interfaces presentation
TERMINAL PRESENTATIONTERMINAL PRESENTATIONTERMINAL PRESENTATIONTERMINAL PRESENTATIONTERMINAL PRESENTATIONTERMINAL PRESENTATION
DataClock / RS485 (5)
• two LED IN inputs (one for access granted, one for access denied), in an
Access Control System (6)
• a relay switch to directly command a physical device such as a door lock
(7),
• a tamper switch (8),
Figure 2 • 2: MorphoAccess
®
J Series rear view (connectors)
5
7
11
8
6
12
9
10
