MORPHOACCESS® J SERIES – User Guide LED IN feature
TERMINAL CUSTOMIZATIONTERMINAL CUSTOMIZATIONTERMINAL CUSTOMIZATIONTERMINAL CUSTOMIZATIONTERMINAL CUSTOMIZATIONTERMINAL CUSTOMIZATION
When the CSC validates the control a timeout must be specified: it defines the
time during which the MorphoAccess
®
will wait for an acknowledgement
signal from the CSC through LED IN signals.
If the controller has only one LED signal dedicated to "access authorized", this
signal must be connected to LED1 input. In this case "access forbidden" signal
will be based on a timeout. "controller ack timeout" value must be defined as
short as possible in a range corresponding to controller reply delay.
A controller with distinct outputs (one for "access forbidden", one for "access
authorized") has to be connected to LED1 and LED2 I/O board
LED IN acknowledgement timeout in 10 ms
app/led IN/controller ack timeout 0 to 268435455
