SAJ H2 - Model Description; Dimension

H2 series
9
2.2.2. Model description
H2
-
x K
-
LS3
-
US
H2
-
x K
-
LS4
-
US
H2: inverter series
x K: rated power of the inverter. For example, 5K indicates the rated power of the inverter is 5 kW.
LS3 : Low voltage with 3 MPPT
LS4 : Low voltage with 4 MPPT
US: This model is applicable to the United States.
2.3. Dimension
Dimension (H*W*D): 810*470*247 mm (31.89*18.504*9.724 inch)
470 mm (18.504")
247 mm (9.724")
810 mm (31.89")
Figure 2.1. Inverter dimension
