SAJ H2 - Datasheet

H2 series
15
2.7. Datasheet
Model
H2-5K-LS3-US
H2-7.6K-LS3-US
H2-9.6K-LS4-US
H2-11.4K-LS4-US
PV String Input
Max. PV array power [Wp]@STC
7500
11400
14400
17100
Max. DC voltage[V]
600
MPPT voltage range[V]
90–510
Nominal DC voltage[V]
380
Start voltage [V]
100
Min. input voltage [V]
80
Max. input current[A]
16/16/16
16/16/16/16
Max. short current [A]
19.2/19.2/19.2
19.2/19.2/19.2/19.2
Quantity of strings per MPPT
1/1/1
1/1/1/1
Quantity of MPPT
3
4
DC switch
Integrated
Battery Port Connection
Battery type
Lead-acid battery/Lithium battery
Voltage range [V]
40–60
Start voltage [V]
42
Max. charging/discharging current
[A]
152
228
AC Output [On-grid]
Rated AC power [W]@208 V AC
4330
6580
8320
9880
Rated AC power [W]@240 V AC
5000
7600
9600
11400
Rated AC current [A]@208/240 V
AC
20.8
31.7
40
47.5
Rated AC voltage and range
L1/L2/N/PE, 120 V AC (split-phase), 208 V AC (2/3 phase)
L1/L2/PE: 240 V AC
⚫ 120 V: 106–132 V
⚫ 240 V: 211–264 V
⚫ 208 V: 183–229 V
