H2 series
16
Model
H2-5K-LS3-US
H2-7.6K-LS3-US
H2-9.6K-LS4-US
H2-11.4K-LS4-US
Rated output frequency and range
[Hz]
⚫ 50 Hz: 47–53
⚫ 60 Hz: 57–63
Power factor [cosφ]
0.8 leading–0.8 lagging
Total harmonic distortion [THDi]
< 3%
AC Output [Back-up Mode]
Rated AC power [W]@208 V AC
4330
6580
8320
9880
Rated apparent power [VA]@240 V
AC
5000
7600
9600
11400
Rated AC current [A]@208/240 V
AC
20.8
31.7
40
47.5
Peak output power [VA, 1 min]
6000
8360
10560
12540
Peak output power [VA, 10s]
7500
11400
14400
17100
Rated output voltage [V]
120 / 208 / 240
Rated output frequency and range
[Hz]
⚫ 50 Hz: 45–55
⚫ 60 Hz: 55–65
Output THDV (@liner load)
< 3%
Switching time
< 10 ms
AC Input [GEN]
Maximum continuous input
power@240V
5000
7600
9600
11400
Rated voltage [V]
120 / 208 / 240
Rated current [A]
20.8
31.7
40
47.5
Efficiency
Maximum efficiency
97.20%
CEC efficiency
96.50%
AC-Bat maximum efficiency
94.20%
Protection &Features
Overvoltage protection
Integrated
ISO monitoring
Integrated
DC component monitoring
Integrated
Monitoring of ground fault current
Integrated
