H2 series
35
Procedure
Step 1. Assemble the cable and OT/DT terminal.
1
2
Figure 5.1. Preparing the grounding cable
1
Heat shrink tube
2
OT/DT terminal
Step 2. Loosen the screw and connect the grounding cable.
Figure 5.2. Connecting the grounding cable
