• Risk of personal injury due to electric shock!
• Ensure that the equipment is powered off before performing wiring operations.
• Improper wiring of AC conductors will result in risk of electrical failure or equipment damage. Please
ensure that all connections are made correctly in accordance with the instructions in this document and
in accordance with local wiring codes and regulations before applying power to the unit.
Procedure
Step 1. Strip off the insulation on the cable ends. (20-mm/0.79-inch length for LOAD and GRID cables;
10-mm/0.39-inch length for GEN cables)
If needed, you can install a terminal on the cable end, as shown below:
