VM1000 Series
‐115‐
Responding Information of Auxiliary:
ADR 01H
CMD 03H
Byte number 04H
F002H high bit 00H
F002H low bit 00H
F003H high bit 00H
F003H high bit 01H
CRCCHK low bit
The CPCCHK is still need to be
calculated
CRCCHK high bit
Table 6-3 The Auxiliary Reading the Frame Format of Responding Information
Register Data that is Written in the Auxiliary :
Example 2: Write the 5000(1388H) in the auxiliary address from F00AH of 02H
VFD.
Command information of host：
ADR 02H
CMD 06H
High bit of data address F0H
Low bit of data address 0AH
High bit of data content 13H
Low bit of data content 88H
CRCCHK low bit
The CPCCHK is still need to be
calculated
CRCCHK high bit
Table 6-4 The Host Written into Command Frame Format
