4.6 Faults Query and Reset step
（1）Faults Status and Reset
In start/stop and running status, the VFD will access to fault status subject to various
internal and external constraints or internal abnormalities. When security conditions
and the devices permit, you need to reset the fault manually so as to return to normal
standby status. Also, automatic fault reset function can be set on the VFD.
（2）Faults Query and Reset Steps
Steps Operation Panel display Indicator Note
Viewing
fault
status
Viewing fault
code
Failure panel displays fault
codes beginning with an E,
and flashes to remind
TUNE/TC
Lights
flash
Indicator refer to 3.1
Fault code refer to
8.1
Viewing
fault
record
1. Viewing E0
parameters for
the latest fault
information
2. E1 ~ E4 are
historical fault
information
In fault status, it can not only
check fault information but
also enter and view various
parameters, modify parameter
values.
——
Reset
Deal with the the
influence of
failure, confirm
the cause of the
malfunction and
eliminate it.
2. Press the
"STOP /
RESET" button
and reset 1
Under the qualified
conditions, the error code is no
longer displayed and return to
the stop/standby status.
TUNE/TC
Lights off
Indicator refer to 3.1
Table 4-8 Faults Query and Reset Step
